Description
Generator
| Prime Power | 50 kVA |
| Prime Power | 44 kW |
| Standby Power | 55 kVA |
| Standby Power | 40 kW |
| Standard Voltage | 400/231 V |
| Revolutions per Minute | 1500 rpm |
| Power Factor | 0,8 cos φ |
Engine
| Brand | FPT IVECO |
| Frequency | 50 |
| Output Power | 50 kW |
| Engine Model | FPT NEF45 AM2.S500 |
| Fuel | Diesel |
| Injection Type | Direct |
| Ventilation Type | Naturally Asp. |
| Number of Cylinders | 4 |
| Cylinder Diameter and Length | 104X132 mm |
| Cylinder Volume | 4,5 L |
| Cooling System | Water |
| Compression Ratio | 17,5:1 |
| Engine Oil Capacity | 12,8 L |
| Cooling Capacity | 18,5 L |
| Governor | Mechanic |
| Air Filter | Dry Element |
| Fuel Capacity at 100% Load | 11,6 L/h |
| Fuel Capacity at 75% Load | 9,8 L/h |
| Fuel Capacity at 50% Load | 6,2 L/h |
| Maximum Exhaust Temperature | 504 °C |
| Exhaust Gas Flow | 211 kg/h |
| Max. Allowable Exhaust Back Pressure | 10 kPa |
| Exhaust Flange Size | 53 mm |
| Air Suction Power | 170 m³/h |
Alternator
| Number of Phases | 3 |
| Power Factor | 0,8 |
| Number of Bearings | Single |
| Number of Poles | 4 |
| Number of Terminal Ends | 6-12 |
| Insulation Class | H |
| Protection Class | IP23 |
| Warning System | AVR |
Dimensions
| Without canopy | |
|---|---|
| Width x Length x Height | 890X1900X1245 mm |
| Fuel Tank Capacity | 150 L |
| Weight | 853 kg |
| With canopy | |
| Width x Length x Height | 890X2600X1450 mm |
| Fuel Tank Capacity | 150 L |
| Weight | 1088 kg |
