Description
Generator
| Prime Power | 30 kVA |
| Prime Power | 24 kW |
| Standby Power | 33 kVA |
| Standby Power | 26 kW |
| Standard Voltage | 400/231 V |
| Revolutions per Minute | 1500 rpm |
| Power Factor | 0,8 cos φ |
Engine
| Brand | FPT IVECO |
| Frequency | 50 |
| Output Power | 31 kW |
| Engine Model | 80313AM1P.S550 |
| Fuel | Diesel |
| Injection Type | Direct |
| Ventilation Type | Naturally Asp. |
| Number of Cylinders | 4 |
| Cylinder Diameter and Length | 115×104 mm |
| Cylinder Volume | 2,9 L |
| Cooling System | Water |
| Compression Ratio | 17:1 |
| Engine Oil Capacity | 8,8 L |
| Cooling Capacity | 9 L |
| Governor | Mechanic |
| Air Filter | Dry Element |
| Fuel Capacity at 100% Load | 6 L/h |
| Fuel Capacity at 75% Load | 4,8 L/h |
| Fuel Capacity at 50% Load | 3,2 L/h |
| Maximum Exhaust Temperature | 525 °C |
| Exhaust Gas Flow | 153 kg/h |
| Max. Allowable Exhaust Back Pressure | 7 kPa |
| Exhaust Flange Size | 52 mm |
| Air Suction Power | 125 m³/h |
Alternator
| Number of Phases | 3 |
| Power Factor | 0,8 |
| Number of Bearings | Single |
| Number of Poles | 4 |
| Number of Terminal Ends | 6-12 |
| Insulation Class | H |
| Protection Class | IP23 |
| Warning System | AVR |
Dimensions
| Without canopy | |
|---|---|
| Width x Length x Height | 830X1600X1102 mm |
| Fuel Tank Capacity | 100 L |
| Weight | 640 kg |
| With canopy | |
| Width x Length x Height | 830X2150X1380 mm |
| Fuel Tank Capacity | 100 L |
| Weight | 848 kg |
