Description
Generator
| Prime Power | 500 kVA |
| Prime Power | 400 kW |
| Standby Power | 550 kVA |
| Standby Power | 440 kW |
| Standard Voltage | 400/231 V |
| Revolutions per Minute | 1500 rpm |
| Power Factor | 0,8 cos φ |
Engine
| Brand | FPT IVECO |
| Frequency | 50 |
| Output Power | 459 kW |
| Engine Model | CR13TE7W.S550 |
| Fuel | Diesel |
| Injection Type | Direct – Common Rail |
| Ventilation Type | T.C & Aftercooled |
| Number of Cylinders | 6 |
| Cylinder Diameter and Length | 135×150 mm |
| Cylinder Volume | 12,88 L |
| Cooling System | Water |
| Compression Ratio | 16,5:1 |
| Engine Oil Capacity | 32 L |
| Cooling Capacity | 38,1 L |
| Governor | Electronic (ECU) |
| Air Filter | Dry Element |
| Fuel Capacity at 100% Load | 100,6 L/h |
| Fuel Capacity at 75% Load | 80,2 L/h |
| Fuel Capacity at 50% Load | 51,5 L/h |
| Maximum Exhaust Temperature | 520 °C |
| Exhaust Gas Flow | 2027 kg/h |
| Max. Allowable Exhaust Back Pressure | 5 kPa |
| Exhaust Flange Size | 94,5 mm |
| Air Suction Power | 1576 m³/h |
Alternator
| Number of Phases | 3 |
| Power Factor | 0,8 |
| Number of Bearings | Single |
| Number of Poles | 4 |
| Number of Terminal Ends | 6-12 |
| Insulation Class | H |
| Protection Class | IP23 |
| Warning System | AVR |
Dimensions
| Without canopy | |
|---|---|
| Width x Length x Height | 1650X3570X1770 mm |
| Fuel Tank Capacity | 750 L |
| Weight | 3408 kg |
| With canopy | |
| Width x Length x Height | 1650X5200X2280 mm |
| Fuel Tank Capacity | 750 L |
| Weight | 4228 kg |
