Description
Generator
| Prime Power | 250 kVA |
| Prime Power | 200 kW |
| Standby Power | 275 kVA |
| Standby Power | 220 kW |
| Standard Voltage | 400/231 V |
| Revolutions per Minute | 1500 rpm |
| Power Factor | 0,8 cos φ |
Engine
| Brand | FPT IVECO |
| Frequency | 50 |
| Output Power | 222 kW |
| Engine Model | NEF67TE8P.S550 |
| Fuel | Diesel |
| Injection Type | Direct Common Rail |
| Ventilation Type | T.C & Aftercooled |
| Number of Cylinders | 6 |
| Cylinder Diameter and Length | 104X132 mm |
| Cylinder Volume | 6,7 L |
| Cooling System | Water |
| Compression Ratio | 17:1 |
| Engine Oil Capacity | 17,2 L |
| Cooling Capacity | 27,6 L |
| Governor | Electronic (ECU) |
| Air Filter | Dry Element |
| Fuel Capacity at 100% Load | 51,5 L/h |
| Fuel Capacity at 75% Load | 41,2 L/h |
| Fuel Capacity at 50% Load | 26,2 L/h |
| Maximum Exhaust Temperature | 500 °C |
| Exhaust Gas Flow | 970 kg/h |
| Max. Allowable Exhaust Back Pressure | 3 kPa |
| Exhaust Flange Size | 70 mm |
| Air Suction Power | 1000 m³/h |
Alternator
| Number of Phases | 3 |
| Power Factor | 0,8 |
| Number of Bearings | Single |
| Number of Poles | 4 |
| Number of Terminal Ends | 6-12 |
| Insulation Class | H |
| Protection Class | IP23 |
| Warning System | AVR |
Dimensions
| Without canopy | |
|---|---|
| Width x Length x Height | 1200X3000X1678 mm |
| Fuel Tank Capacity | 450 L |
| Weight | 1850 kg |
| With canopy | |
| Width x Length x Height | 1200X4100X1930 mm |
| Fuel Tank Capacity | 450 L |
| Weight | 2395 kg |
