Description
Generator
| Prime Power | 400 kVA |
| Prime Power | 320 kW |
| Standby Power | 440 kVA |
| Standby Power | 352 kW |
| Standard Voltage | 400/231 V |
| Revolutions per Minute | 1500 rpm |
| Power Factor | 0,8 cos φ |
Engine
| Brand | FPT IVECO |
| Frequency | 50 |
| Output Power | 387 kW |
| Engine Model | CURSOR13TE3A.S551 |
| Fuel | Diesel |
| Injection Type | Direct E.U.I |
| Ventilation Type | T.C & Aftercooled |
| Number of Cylinders | 6 |
| Cylinder Diameter and Length | 135×150 mm |
| Cylinder Volume | 12,88 L |
| Cooling System | Water |
| Compression Ratio | 16,5:1 |
| Engine Oil Capacity | 35 L |
| Cooling Capacity | 68 L |
| Governor | Electronic (ECU) |
| Air Filter | Dry Element |
| Fuel Capacity at 100% Load | 85,8 L/h |
| Fuel Capacity at 75% Load | 70,4 L/h |
| Fuel Capacity at 50% Load | 42,8 L/h |
| Maximum Exhaust Temperature | 445 °C |
| Exhaust Gas Flow | 2210 kg/h |
| Max. Allowable Exhaust Back Pressure | 5 kPa |
| Exhaust Flange Size | 94,5 mm |
| Air Suction Power | 1770 m³/h |
Alternator
| Number of Phases | 3 |
| Power Factor | 0,8 |
| Number of Bearings | Single |
| Number of Poles | 4 |
| Number of Terminal Ends | 6-12 |
| Insulation Class | H |
| Protection Class | IP23 |
| Warning System | AVR |
Dimensions
| Without canopy | |
|---|---|
| Width x Length x Height | 1400X3500X1824 mm |
| Fuel Tank Capacity | 600 L |
| Weight | 2927 kg |
| With canopy | |
| Width x Length x Height | 1400X4800X2030 mm |
| Fuel Tank Capacity | 600 L |
| Weight | 3527 kg |
