Description
Generator
| Prime Power | 230,0 kVA |
| Prime Power | 184,0 kW |
| Standby Power | 253,0 kVA |
| Standby Power | 202,4 kW |
| Standard Voltage | 400/231 V |
| Revolutions per Minute | 1500 rpm |
| Rated At Power Factor | 0,8 cos φ |
Engine
| Brand | BAUDOUIN |
| Model | 6M16G4D0-S |
| Cylinder Configuration | In-Line |
| Number of Cylinders | 6 |
| Cylinder Volume | 9,726 |
| Cylinder Diameter | 126 |
| Cylinder Length | 130 |
| Compression Ratio | 17:1 |
| Ventilation Type | Turbo-charged – Aftercooler |
| Governor Type | Electronic |
| Cooling Type | Water |
| Cooling Capacity | 42 L |
| Total Oil Capacity | 22 L |
| Electrical System (DC) | 24 V |
| Speed/Frequency | 1500/50 rpm |
| Engine Power | 238 kW |
| 110% Fuel Consumption at Load | 56,4 L |
| Fuel Consumption at 100% Load | 50,9 L |
| 75% ESP Fuel Consumption at Load | 38 L |
| 50% ESP Fuel Consumption at Load | 25,8 L |
| Exhaust Temperature | 600 °C |
| Exhaust Gas Flow | 44,4 m³/min |
| Combustion Air Flow | 15,6 m³/min |
| Cooling Fan Flow | 415 m³/min |
Alternator
| Number of Phases | 3 |
| Power Factor | 0,8 |
| Number of Bearings | Single |
| Number of Poles | 4 |
| Number of Terminal Ends | 6-12 |
| Insulation Class | H |
| Protection Class | IP23 |
| Warning System | AVR |
Dimensions
| Without canopy | |
|---|---|
| Width x Length x Height | 1200X3000X1624 mm |
| Weight | 2239 kg |
| Fuel Tank Capacity | 450 L |
| With canopy | |
| Width x Length x Height | 1200X4100X1930 mm |
| Weight | 2784 kg |
| Fuel Tank Capacity | 450 L |
