Description
Generator
| Prime Power | 10 kVA |
| Prime Power | 8 kW |
| Standby Power | 11 kVA |
| Standby Power | 8,8 kW |
| Standard Voltage | 400/231 V |
| Revolutions per Minute | 1500 rpm |
| Power Factor | 0,8 cos φ |
Engine
| Brand | YANGDONG |
| Model | YDD380D |
| Cylinder Configuration | In Line |
| Number of Cylinders | 3 |
| Cylinder Volume | 1,35 |
| Cylinder Diameter | 80 mm |
| Cylinder Length | 90 mm |
| Compression Ratio | 18 |
| Ventilation Type | Natural Aspirasyon |
| Governor Type | Mechanic |
| Cooling Type | Water |
| Total Cooling Capacity | 3,4 L |
| Total Oil Capacity | 4,5 L |
| Electrical System (DC) | 12 V |
| Speed/Frequency | 1500/50 rpm / Hz |
| Engine Power | 11 KW kW |
| 110% Fuel Consumption at Load | – L |
| Fuel Consumption at 100% Load | 3,1 L |
| 75% ESP Fuel Consumption at Load | 2,86 L |
| 50% ESP Fuel Consumption at Load | 2,23 L |
| Exhaust Temperature | 500 °C |
| Exhaust Gas Flow | 1,96 m³/min |
| Combustion Air Flow | m3/min TBA |
| Cooling Fan Flow | m3/min TBA |
Alternator
| Number of Phases | 3 |
| Power Factor | 0,8 |
| Number of Bearings | Single |
| Number of Poles | 4 |
| Number of Terminal Ends | 6-12 |
| Insulation Class | H |
| Protection Class | IP23 |
| Warning System | AVR |
Dimensions
| Without canopy | |
|---|---|
| Width x Length x Height | 730X1300X930 mm |
| Fuel Tank Capacity | 100 L |
| Weight | 385 kg |
| With canopy | |
| Width x Length x Height | 730X2100X1200 mm |
| Fuel Tank Capacity | 100 L |
| Weight | 541 kg |
