Description
Generator
| Prime Power | 100 kVA |
| Prime Power | 80 kW |
| Standby Power | 105 kVA |
| Standby Power | 84 kW |
| Standard Voltage | 400/231 V |
| Revolutions per Minute | 1500 rpm |
| Power Factor | 0,8 cos φ |
Engine
| Brand | YANGDONG |
| Model | YD4GZLD |
| Cylinder Configuration | In Line |
| Number of Cylinders | 4 |
| Cylinder Volume | 4,3 |
| Cylinder Diameter | 110 |
| Cylinder Length | 118 |
| Compression Ratio | 18 |
| Ventilation Type | Turbo Charge |
| Governor Type | Electronic |
| Cooling Type | Water |
| Total Cooling Capacity | 7,2 L |
| Total Oil Capacity | 17 L |
| Electrical System (DC) | 12 V |
| Speed/Frequency | 1500/50 rpm / Hz |
| Engine Power | 93 KW kW |
| 110% Fuel Consumption at Load | – L |
| Fuel Consumption at 100% Load | 22,1 L |
| 75% ESP Fuel Consumption at Load | 18,9 L |
| 50% ESP Fuel Consumption at Load | 14,2 L |
| Exhaust Temperature | 550 °C |
| Exhaust Gas Flow | 13,53 m³/min |
| Combustion Air Flow | m3/min TBA |
| Cooling Fan Flow | m3/min TBA |
Alternator
| Number of Phases | 3 |
| Power Factor | 0,8 |
| Number of Bearings | Single |
| Number of Poles | 4 |
| Number of Terminal Ends | 6-12 |
| Insulation Class | H |
| Protection Class | IP23 |
| Warning System | AVR |
Dimensions
| Without canopy | |
|---|---|
| Width x Length x Height | 1000X2000X1090 mm |
| Fuel Tank Capacity | 215 L |
| Weight | 1021 kg |
| With canopy | |
| Width x Length x Height | 1000X3100X1600 mm |
| Fuel Tank Capacity | 215 L |
| Weight | 1341 kg |
