Description
Generator
| Prime Power | 60 kVA |
| Prime Power | 48 kW |
| Standby Power | 66 kVA |
| Standby Power | 52,8 kW |
| Standard Voltage | 400/231 V |
| Revolutions per Minute | 1500 rpm |
| Power Factor | 0,8 cos φ |
Engine
| Brand | PERKINS |
| Model | 1103A-33TG2 |
| Cylinder Configuration | Inline |
| Number of Cylinders | 3 |
| Cylinder Volume | 3,3 |
| Cylinder Diameter | 105 |
| Cylinder Length | 127 |
| Compression Ratio | 17,25:1 |
| Ventilation Type | Turbo-charged |
| Governor Type | Mechanic |
| Cooling Type | Water |
| Cooling Capacity | 10,2 L |
| Total Oil Capacity | 7,9 L |
| Electrical System (DC) | 12 V |
| Speed/Frequency | 1500/50 rpm / Hz |
| Engine Power | 60,5 kW |
| 110% Fuel Consumption at Load | 15,6 L |
| Fuel Consumption at 100% Load | 14,1 L |
| 75% ESP Fuel Consumption at Load | 10,5 L |
| 50% ESP Fuel Consumption at Load | 7,3 L |
| Exhaust Temperature | 543 °C |
| Exhaust Gas Flow | 9,8 m³/min |
| Combustion Air Flow | 3,8 m³/min |
| Cooling Air Flow | 110,4 m³/min |
Alternator
| Number of Phases | 3 |
| Power Factor | 0,8 |
| Number of Bearings | Single |
| Number of Poles | 4 |
| Number of Terminal Ends | 6-12 |
| Insulation Class | H |
| Protection Class | IP23 |
| Warning System | AVR |
Dimensions
| Without canopy | |
|---|---|
| Width x Length x Height | 890X1900X1231 mm |
| Fuel Tank Capacity | 150 L |
| Weight | 853 kg |
| With canopy | |
| Width x Length x Height | 890X2600X1450 mm |
| Fuel Tank Capacity | 150 L |
| Weight | 1088 kg |
