Description
Generator
| Prime Power | 550 kVA |
| Prime Power | 440 kW |
| Standby Power | 600 kVA |
| Standby Power | 480 kW |
| Standard Voltage | 400/231 V |
| Revolutions per Minute | 1500 rpm |
| Power Factor | 0,8 cos φ |
Engine
| Engine Model | SC25G690D2 |
| Standby Power | 505 kW |
| Prime Power | 459 kW |
| Number of Transfers | 1500 rpm |
| Cylinder Volume | 25,8 L |
| Number of Cylinders | 12 V |
| Bore x Stroke | 135 X 150 mm |
| Compression Ratio | 16:1 |
| Governor Type | Electronic |
| Ventilation System | TURBOCHARGED – AAC |
| Injection System | Direct |
| Cooling System | Water |
| 100% Fuel Consumption at Load | 114 L/h |
| 75% Fuel Consumption at Load | 86 L/h |
| Fuel Consumption at 50% Load | 61 L/h |
| Total Oil Capacity | 65 L |
| Total Cooling Capacity | 147 L |
Alternator
| Number of Phases | 3 |
| Power Factor | 0,8 |
| Number of Bearings | Single |
| Number of Poles | 4 |
| Number of Terminal Ends | 6-12 |
| Insulation Class | H |
| Protection Class | IP23 |
| Warning System | AVR |
Dimensions
| Without canopy | |
|---|---|
| Width x Length x Height | 1650X3500X2232 mm |
| Fuel Tank Capacity | 950 L |
| Weight | 4163 kg |
| With canopy | |
| Width x Length x Height | 1650X5200X2380 mm |
| Fuel Tank Capacity | 950 L |
| Weight | 4998 kg |
