Description
Generator
| Prime Power | 408 kVA |
| Prime Power | 326,4 kW |
| Standby Power | 450 kVA |
| Standby Power | 360 kW |
| Standard Voltage | 400/231 V |
| Revolutions per Minute | 1500 rpm |
| Power Factor | 0,8 cos φ |
Engine
| Brand | PERKINS |
| Model | 2206A-E13TAG3 |
| Cylinder Configuration | Inline |
| Number of Cylinders | 6 |
| Cylinder Volume | 12,5 |
| Cylinder Diameter | 130 |
| Cylinder Length | 157 |
| Compression Ratio | 16,3:1 |
| Ventilation Type | Turbo-charged – Intercooler |
| Governor Type | Elektronic/ECM |
| Cooling Type | Water |
| Cooling Capacity | 51,4 L |
| Total Oil Capacity | 40 L |
| Electrical System (DC) | 24 V |
| Speed/Frequency | 1500/50 rpm / Hz |
| Engine Power | 412,5 kW |
| 110% Fuel Consumption at Load | 90 L |
| Fuel Consumption at 100% Load | 81 L |
| 75% ESP Fuel Consumption at Load | 62 L |
| 50% ESP Fuel Consumption at Load | 42 L |
| Exhaust Temperature | 630 °C |
| Exhaust Gas Flow | 72,5 m³/min |
| Combustion Air Flow | 26,4 m³/min |
| Cooling Air Flow | 654 m³/min |
Alternator
| Number of Phases | 3 |
| Power Factor | 0,8 |
| Number of Bearings | Single |
| Number of Poles | 4 |
| Number of Terminal Ends | 6-12 |
| Insulation Class | H |
| Protection Class | IP23 |
| Warning System | AVR |
Dimensions
| Without canopy | |
|---|---|
| Width x Length x Height | 1650X3400X2085 mm |
| Fuel Tank Capacity | 750 L |
| Weight | 3285 kg |
| With canopy | |
| Width x Length x Height | 1650X5200X2280 mm |
| Fuel Tank Capacity | 750 L |
| Weight | 4105 kg |
