Description
Generator
| Prime Power | 200 kVA |
| Prime Power | 160 kW |
| Standby Power | 220 kVA |
| Standby Power | 176 kW |
| Standard Voltage | 400/231 V |
| Revolutions per Minute | 1500 rpm |
| Power Factor | 0,8 |
Engine
| Brand | DOOSAN |
| Engine Model | P086TI |
| Power | 194/263 kW |
| Revolutions per Minute | 1500 rpm |
| Cylinder Volume | 8,071 |
| Number and Type of Cylinders | 6 Inline |
| Bore x Stroke | 111×139 mm |
| Compression Ratio | 16,4:1 |
| Governor Type | Electronic |
| Ventilation System | Turbo CAC |
| Injection System | Direct |
| Cooling Type | Water |
| Electrical System | 24 V |
| Oil Capacity | 15,5 L |
| Cooling Capacity | 44 L |
| Fuel Tank Capacity | 300 L |
| Maximum Exhaust Temperature | 509 °C |
| Exhaust Gas Flow | 33,9 |
| Max. Allowable Exhaust Back Pressure | 5,9 kPa |
| Cooling Fan Flow | 190 m³/min |
| Fuel Consumption at 50% Load | 21,1 L/h |
| 75% Fuel Consumption at Load | 31,7 L/h |
| 100% Fuel Consumption at Load | 43,1 L/h |
Alternator
| Number of Phases | 3 |
| Power Factor | 0,8 |
| Number of Bearings | Single |
| Number of Poles | 4 |
| Number of Terminal Ends | 6-12 |
| Insulation Class | H |
| Protection Class | IP23 |
| Warning System | AVR |
Dimensions
| Without canopy | |
|---|---|
| Width x Length x Height | 1100X2500X1460 mm |
| Fuel Tank Capacity | 300 L |
| Weight | 1775 kg |
| With canopy | |
| Width x Length x Height | 1100X3700X1680 mm |
| Fuel Tank Capacity | 300 L |
| Weight | 2180 kg |
